Description Teagle Tomahawk Bale Straw Mill – Suitable for 1.5m Bales – T505M For straightforward bale processing the 404M/505M/505XLM range offers fast effective milling of straw and miscanthus to a very consistent and fine length. Operation: Blow straw up to 30ft, discharge to one or both sides of the tractor. Alternative delivery chutes are available to suit your requirements. The Tomahawk 404 and 505 models use rotating and static blades to chop dry material to around 50mm. The chop length can easily be adjusted by moving the rotor, thereby changing the clearance between the blades. An optional short chop kit can be fitted to reduce the chop length further. Easy control of output by adjusting the speed of drum rotation. Specifications: Operating Width – 2.13m Operating Width with Straw Giraffe – 2.28m Straw Giraffe Discharge Height – 1.84m Weight – 970kg PTO power Required – 80hp Maximum Round Bale Diameter – 1.5m Maximum Rectangular Bale Size – N/A Drum Diameter – 1.83m Drum Length (standard) – 1.55m Long Drum (optional) – 1.85m Height Overall with machine on ground – 2.44m Width with chutes closed: 1.98m Lower chute discharge height: 0.4m Upper chute discharge height: 1.14m Length Overall: 2.36m The 404M/505M/505XL range is suitable for dry material only, and will not cut silage or straw that has become damp as it will block the cutting rotor and chutes. All prices include GST. Please allow extra for freight. Delivery available through Australia Post for small items. Postage calculated at checkout. Select ‘Quote’ at check out for freight quote on larger items. Delivery is available Australia Wide. Dealer enquiries welcome. Finance is now available! Contact Farm Supplies today for sale or more information! Photos are for illustration only, and actual product may vary from those shown. Prices are correct at time of posting the ad, but are still subject to change. E & OE.
