Camera Image Sensor 1/2.7″ CMOS Effective Pixels 2560(H)×1440(V), 4MP Scanning System Progressive Electronic Shutter Speed PAL: 1/25~1/100000s NTSC: 1/30~1/100000s Minimum Illumination 0.04Lux/F2.0, 30IRE, 0Lux IR on S/N Ratio More than 65dB IR Distance Up to 20m (66feet) IR On/Off Control Auto / Manual Lens Lens Type Fixed lens / Fixed iris Mount Type Board-in Focal Length 3.6mm (6mm Optional) Max Aperture F2.0 Angle of View 3.6mm: 107°x89°x48°(diagonal × horizontal × vertical) 6mm: 61°x54°x31°(diagonal × horizontal × vertical) Focus Control N/A Close Focus Distance 1.1m/2.7m (3.6ft/8.6ft) DORI Distance Lens Detect Observe Recognize Identify 3.6mm 64.0 m (210.0 ft) 25.6 m (84.0 ft) 12.8 m (42.0 ft) 6.4 m (20 ft) 6mm 106.7 m (350.0 ft) 42.7 m (140.0 ft) 21.3 m (70.0 ft) 10.7 m (32.0 ft) Pan / Tilt / Rotation Pan/Tilt/Rotation Pan: 0° ~ 360° Tilt: 0° ~ 90° Rotation: 0° ~ 360° Video Resolution 4MP (2560×1440) Frame Rate 25/30fps@4MP,25/30fps@1080P Video Output 1-channel BNC high definition video output / CVBS video output (Can switch) Day/Night Auto (ICR) / Manual OSD Menu Multi-language BLC Mode BLC / HLC / DWDR WDR DWDR Gain Control AGC Noise Reduction 2D White Balance Auto / Manual Smart IR Auto / Manual Certifications Certifications CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) Interface Audio Interface N/A Eelectrical Power Supply 12V DC ±30% Power Consumption Max. 3.7W (12V DC, IR on) Environmental Operating Conditions -40°C ~ 60°C (-40°F ~ 140°F) / Less than 95% RH * Start up should be done at above -40°C (-40°F) Storage Conditions -40°C ~ 60°C (-40°F ~ 140°F) / Less than 95% RH Ingress Protection & Vandal Resistance IP67 Construction Casing Plastic Dimensions 70mm×70mm×149mm (2.76″×2.76″×5.87″) Net Weight 0.15kg (0.33lb) Gross Weight 0.19kg (0.42lb)
