$67.53
$100.62
Recording Video CompressionH.265 Pro /H.265 Pro/H.265/H.264 /H.264 Encoding Resolution When 1080p Lite mode is not enabled: 4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode is enabled: 4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF Frame Rate Main stream: When 1080p Lite mode is not enabled: For 4 MP stream access: 4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) When 1080p Lite mode is enabled: 4 MP lite/3 MP@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) Sub-stream: WD1/4CIF@12fps; CIF@25fps (P)/30fps (N) Video Bitrate32 Kbps to 6 Mbps Dual-StreamSupport Stream TypeVideo, Video & Audio Audio CompressionG.711u Audio Bitrate64 Kbps Video And Audio IP Video Input 1-ch (up to 5-ch) Enhanced IP mode on: 2-ch (up to 6-ch), each up to 4 Mbps Up to 6 MP resolution Support H.265 /H.265/H.264 /H.264 IP cameras Incoming Bandwidth24 Mbps Analog Video Input 4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection HDTVI Input 4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60 *: The 3 MP signal input is only available for channel 1 of DS-7104HQHI-K1. AHD Input4 MP, 1080p25, 1080p30, 720p25, 720p30 HDCVI Input4 MP, 1080p25, 1080p30, 720p25, 720p30 CVBS InputSupport VGA Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz HDMI Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz Audio Input 1-ch, RCA (2.0 Vp-p, 1 KΩ) 4-ch via coaxial cable Audio Output1-ch, RCA (Linear, 1 KΩ) Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input) Synchronous Playback4-ch Network Total Bandwidth72 Mbps Remote Connection32 Network ProtocolTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF Network Interface1, RJ45 10M/100M self-adaptive Ethernet interface Auxiliary Interface SATA1 SATA interface CapacityUp to 6 TB capacity for each disk Alarm In/OutN/A USB InterfaceReal panel: 2 × USB 2.0 General Power Supply12 VDC, 1.5 A Consumption≤ 8 W Working Temperature-10 °C to 55 °C ( 14 °F to 131 °F) Working Humidity10% to 90% Dimension (W × D × H)200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch) ≤ 1 kg (2.2 lb)
Audio Video Intercom
