MidNite Solar MNPV6-DISCO AC MICRO

The MidNite MNPV6-DISCO AC MICRO is an AC string combiner for 240 Volt AC strings, such as those coming from micro-inverter trunk cables. The combiner has room for 3 of the MidNite 240V AC breakers. In case 120V AC single-phase is needed, the unit can handle 6 of the MidNite 120V AC breakers. It contains a neutral busbar and ground busbar as well. The combiner is NEMA-3 rated for outdoor use. The combiner comes without breakers! Usually three MNEAC20-2P breakers are installed in it, though any of the DIN-rail mounted AC breakers will work. The AC MICRO can be used for up to 150 amps and 1/0 wire. The unit is Load Break rated and can be locked in the off position. Features Lockable disconnect Includes neutral busbar NEMA-3R rated for outdoor use UL/CSA listed for North America Knockouts for wiring in sides and bottom All aluminum powder coated housing that won’t rust Flip up cover that can stay in the open position during installation Chassis ground bus bar with 14 useable openings (10 #14-6 and 4#1/0-14) Standard din rail to mount up to three 240V AC dual-pole breakers Dead front cover snaps into place after wiring is complete for safety Top surface is available to bring conduit in from directly above the enclosure Combines up to three 240V split-phase AC micro-inverter strings or six 120V AC strings
