13HP 42CFM Compressor Diesel 160 Litre 145PSI

The high powered MC160112D diesel air compressor is fully compliant with mine site regulations, featuring a pressure vessel design registered for mine use. Its cast-iron air pump ensures long-lasting performance, while the high-pressure pump makes it ideal for even the toughest applications. Powered by a reliable and economical diesel engine, this unit is designed for durability and efficiency. This unit is easy transport thanks to a strong structure and forklift points. Built to Australian Standards with a 20 lifespan, the MC160112D can withstand years of heavy commercial use! Motor Type : Single Cylinder, 4-Stroke, Air-Cooled, 192 Engine Compression Ratio : 19:01 Starting System : Electric Starter, Recoil Start Rotation Direction : Clockwise, (Viewed From Flywheel) Engine Lubricant : SAE 15W40 (Above CC Grade) Motor Oil Capacity : 1.65 l Battery : 12V 20Ah Compressor : Three Cylinder, Cast Iron Construction Compressor Drive : Twin V-Belt Compressor rpm : 904 rpm Compressor Displacement : 42CFM / 1189 LPM Compressor Airflow : 32 CFM, 906 LPM Compressor Oil : Compressor 20W30 Non-Detergent Australian Standards : AS1210: 2010 Class 3 Design Pressure : 900 kPA Working Pressure : 800 kPA Test Pressure : 1287 kPA Pressure Gauge : High Pressure gauge MPA/PSI Outlets : ‘Easy Start’ Manifold Pressure Release Tap 155 psi (10.7 bar) Relief Valve 2′ 1/2″ Ball Valve 1 inch Drain Tap  *DRAIN DAILY   1 YEAR WARRANTY SERVICE DETAILS : Engine Air Filter: AIR-192 Engine Oil Filter: GPDIESELOIL PUMP OIL: ISO100 250 Hourly/6 Monthly PUMP AIR FILTER: PA1712 x 3 Belt: B-1956 / B77 Check Pump Head Bolts Every 60 Days Additional Information Air Flow (CFM) 42 Air Pressure (PSI) 145 Air Tank Size (L) 160 Engine Power (Hp) 13 Cooling Air Cooled Fuel Tank Size (L) 4.7 Dryer Not included in this model Weight (kg) 295 Dimensions (cm) 141L x 61W x 125H
