Description Key Features Run time for load W 3m Max. Capacity Used 100% Output power capacity 1.05kWatts / 1.5kVA Output Connections (4) Universal receptacle (Battery Backup) Nominal Output Voltage 230V Nominal Input Voltage 230V Input Connections IEC 60320 C14 APC Easy UPS SMV 1500VA, Universal Outlet, 230V Easy UPS provides power protection for unstable power conditions, ensuring consistent and reliable connectivity at the most critical moments. Includes: Documentation CD, USB cable, User manual Automatic Voltage Regulation (AVR) Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment. Cold-start capable Provides temporary battery power when the utility power is out. LCD graphics display Text and mimic diagrams that display modes of operation, system parameters and alarms. Pure sine wave output on battery Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics. Easy UPS Features & Benefits Manageability Audible alarms Provides notification of changing utility power and UPS power conditions LED Indicators Provide easy-to-read status of the unit and utility power conditions. Features Cold-start capable Provides temporary battery power when the utility power is out. Sleek design Slim, modern design can be upright, flat, or wall-mounted to comfortably fit any electronics set-up and complement home décor. Boost Automatic Voltage Regulation (AVR) Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery. Transformer-block spaced outlets Protect equipment with input transformer blocks without blocking access to other receptacles. Safety Safety-agency approved Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment. Availability Advanced Safety Features Safeguard your Home UPS from overloads, excessive mains voltages, short circuits, installation mishaps and battery damage due to low voltage situations. Battery failure notification Provides early-warning fault analysis on batteries enabling timely preventive maintenance Intelligent battery management Maximizes battery performance, life, and reliability through intelligent, precision charging. Protection Battery and surge protected outlets Back up and protect your hardware and data during power outages, surges and spikes. Battery backup and surge protection Outlets provide abundant runtime for network gateway equipment and other critical low-power devices, allowing for hours of internet access during a power outage. Output Max Configurable Power (Watts) 1.05kWatts / 1.5kVA Output Frequency (sync to mains) 50/60 Hz /- 1 Hz Unsynchronised Load Crest Factor 3 : 1 Topology Line interactive Waveform type Sine wave Transfer Time 2 ms typical Input Input frequency 45 – 65 Hz Auto-sensing Input voltage range for main operations 160 – 295V Number of Power Cords 1 Other Input Voltages 220, 240 Batteries & Runtime Battery type Lead-acid battery Typical recharge time 4hour(s) Expected Battery Life (years) 3 – 5 Battery Charge Power (Watts) 54Watts Battery Volt-Amp-Hour Capacity 216 Communications & Management Interface Port(s) USB Audible Alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm Physical Maximum Height 220MM, 22.0CM Maximum Width 160MM, 16.0CM Maximum Depth 410MM, 41.0CM Net Weight 17.8KG Shipping weight 20.75KG Shipping Height 339MM, 33.9CM Shipping Width 272MM, 27.2CM Shipping Depth 508MM, 50.8CM Environmental Operating Temperature 0 – 40 °C Operating Relative Humidity 0 – 90 % Operating Elevation 0 – 3048meters Storage Temperature -10 – 40 °C Storage Elevation 0 – 3048meters Audible noise at 1 meter from surface of unit 45.0dBA Conformance Approvals CE Standard warranty 2 years repair or replace
